(VAOF06) 0.6ml Cuvette, Fused, Lightpath 10mm, Large Opening, 5x24x14 mm, 2 Clear Windows

Description VAOF06 Fused Quartz Micro Cuvette is a 0.6 ml capacity custom-dimension cuvette designed for absorption spectroscopy with a 10 mm optical path length. Its low-profile geometry (5 × 24 mm) and wide inner width (20 mm) make it ideal for applications that require large opening designs and small sample volumes. This model reflects our ability to manufacture non-standard fused quartz cuvettes, offering both precision and compatibility with compact and OEM analytical instruments. Key Features 10 mm optical path — standard for quantitative absorption measurements. 0.6 ml capacity — suitable for low-volume sample analysis. Custom large opening design — makes pipetting and cleaning easier. Fused quartz construction — ensures excellent UV transparency, thermal stability, and chemical resistance. Broad wavelength range: 190–2500 nm — compatible with UV/VIS/NIR analytical instruments. Typical Applications Low-volume absorption spectroscopy OEM and custom optical system integration Biochemical and clinical analysis Environmental and water quality testing R&D and trace analysis Fused Fabrication Notes Fused quartz provides outstanding optical transmission and temperature stability up to 600 °C. Not suitable for hydrofluoric acid (HF) or strong organic solvents such as toluene and acetone. Powder seams may discolor over time but do not affect optical accuracy. Typical dimensional tolerance: ±0.06–0.08 mm. Cuvette Specifications Type Micro Quartz Cuvette Optical Path Length 10 mm Article No. VAOF06 Volume 0.6 ml Measuring Method Absorption Cells Clear Walls 5 × 24 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 5 mm Width (Inside) 20 mm Width (Outside) 24 mm Depth (Inside) 10 mm Depth (Outside) 14 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Fused* Package Cell Only Note: VAOF06 is a fused quartz micro cuvette with a custom large opening design, ideal for low-volume sample handling in precision absorption spectroscopy and OEM instrument setups. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VCOF20-N) 3mL Custom Cuvette, 5 Windows, no cover, Fused, Lightpath 20mm, 8.5x21x21 mm 100 gIn Stock$293.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VCOF20Q) 3mL Custom Cuvette, 5 Windows, quartz cover, Fused, Lightpath 20mm, 8.5x21x21 mm 100 gIn Stock$318.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOB20) 2ml Cuvette, Bonded, Lightpath 8.5mm, Large Opening, 8x45x12.5 mm, 2 Windows 100 gIn Stock$41.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VFOM14) 14ml Fluorescence Cuvette, Molded, Dual Lightpath 10/ 40mm, Open-Top, 4 Clear Windows 100 gIn Stock$396.00Add to cart Add to Wishlist Add to Wishlist
