(V5ML20Q) 8 mL Large Cuvette, 5 Windows, Quartz Cover, Molded, Lightpath 20mm, 22x24x24 mm

Description V5ML20Q Large Quartz Cuvette is a 5-window molded quartz cuvette with a 20 mm optical path length and 8 ml volume. It is equipped with a quartz cover, offering better chemical compatibility and sample protection than PTFE lids, making it ideal for advanced fluorescence and absorbance measurements. Key Features 20 mm optical path — enhances absorbance sensitivity and improves fluorescence detection signal. 5-window design — allows multiple measurement geometries, including side fluorescence detection and front-face illumination. 8 ml capacity — suitable for moderate volume photochemical and analytical experiments. Quartz cover — offers higher chemical resistance and improved optical compatibility compared with PTFE covers. Molded quartz fabrication — ensures excellent dimensional accuracy and optical clarity. Typical Applications High-sensitivity fluorescence and absorbance spectroscopy in UV/VIS/NIR ranges. Photochemical and kinetic studies with controlled sample conditions. Environmental, chemical, and material analysis requiring stable measurement geometry. Advanced R&D laboratories demanding high optical precision. Molded Fabrication Notes High dimensional accuracy and smooth optical surfaces reduce stray light and scattering. Quartz cover provides better sealing and chemical durability than PTFE but is not completely airtight. Excellent transmission across 190–2500 nm wavelength range. Not compatible with HF or certain strong organic solvents such as toluene and acetone. Cuvette Specifications Type Large Capacity Cuvette Optical Path Length 20 mm Article No. V5ML20Q Volume 8 ml Measuring Method Fluorescence Cells Clear Walls 22 × 24 mm Number of Windows 5 Wavelength Range UV/VIS (190 – 2500 nm) Height 22 mm Width (Inside) 20 mm Width (Outside) 24 mm Depth (Inside) 20 mm Depth (Outside) 24 mm Cover Material Quartz Fabrication Method Molded* Package Cell & Cover Note: Quartz cover provides better resistance to solvents and optical compatibility compared with PTFE lids. However, it is not designed for fully airtight sealing. For oxygen-sensitive or volatile samples, consider additional sealing accessories. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VFFL30N) 27 mL Large Cuvette, 4 Windows, No Cover, Fused, Lightpath 30mm, 32x34x34 mm 200 gIn Stock$196.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (V5ML20P) 8 mL Large Cuvette, 5 Windows, PTFE Cover, Molded, Lightpath 20mm, 22x24x24 mm 100 gIn Stock$328.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (V5ML20N) 8 mL Large Cuvette, 5 Windows, No Cover, Molded, Lightpath 20mm, 22x24x24 mm 100 gIn Stock$309.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VFFL20N) 8 mL Large Cuvette, 4 Windows, No Cover, Fused, Lightpath 20mm, 22x24x24 mm 100 gIn Stock$154.00Add to cart Add to Wishlist Add to Wishlist
