Description ChamSys MagicQ DIN Main features and specification for ChamSys MagicQ DIN: Ideal for installations and architectural settings 24 universes direct, expandable to 48 Two RDM enabled DMX Outputs (Phoeonix Screw Terminal connectors) Inbuilt Wi-Fi for programming and remote control Four 10Scene ports for connection of up to forty 10Scene wall plate Features the same software as MagicQ Consoles The full power of MagicQ software in a DIN rail mount solution. MagicQ DIN supports all MagicQ features, including scheduled events, UDP, OSC and other remote protocols, making it ideal for cabinet installation in control rooms and suitable for theatres, houses of worship, and any venue requiring powerful control that offers the advanced capabilities of MagicQ such as pixel mapping and multi-element fixture control. Its 24 universes of DMX output are expandable to 48 and connectivity features include two RDM-enabled DMX outputs, inbuilt Wi-Fi for programming and remote control, and four 10Scene ports for connecting up to forty 10Scene wall plates. Hardware Specifications: Universes supported: 24, expandable to 48 via licence upgrade DMX Outputs Pheonix Screw Terminal: 2 External Monitor: 1920 x 1080 HDMI Inbuilt Wi-Fi: Yes Network Port: 1 USB Ports: 2 Power Input: 12v DC Software Specifications: Max Number of DMX Channels: 12288 *expandable to 24576 Max Number of Fixtures Supported: 12288 *expandable to 24576 Max Number of Cues: 5000 Max Number of Cue Stacks: 2000 Max Number of Groups: 5000 Max Number of Palettes: 4096 Number of Media Server Layers Supported: 50 (each different content) OSC Supported: Yes RDM Autopatch for fast show patching Fixture library of over 48,000 fixture files Built in FX generator Colour picker and Gel inbuilt Gel library Rack Weights and Dimensions: Width : 200mm (7.8 inches) Depth: 165mm (6.5 inches) Height: 40mm (1.6 inches) Weight: 0.65kg (1.43lb) Included Accessories: Wi-Fi Antenna: 1 DIN Rail Mount Clips: 2 10Scene Connectors: 4 12v Power Supply: 1 Boxed Weights and Dimensions: Width: 268mm (10.5 inches) Depth: 220mm (8.7 inches) Height: 130mm (5.1 inches) Weight: 1.04kg (2.29 lb) Did not find what you need? Send us an enquiry _______________________________ Glossary: ChamSys Magic Q DIN Brand ChamSys
