(VAOF25) 2.5ml Absorption Cuvette, Fused, Lightpath 1.5mm, 50x38x4.5 mm, 2 Clear Windows

Description VAOF25 Fused Quartz Absorption Cuvette is a 2-window cuvette with a 1.5 mm optical path length and a 2.5 ml volume. It features a wide clear wall design optimized for high-concentration or strongly absorbing samples, minimizing absorbance saturation. Fused fabrication provides excellent chemical and thermal resistance, ensuring reliable optical performance in demanding analytical applications. Key Features 1.5 mm optical path length — ideal for high-concentration samples or strong absorbance measurements. 2-window design — optimized for straight-beam UV/VIS absorbance spectroscopy. Fused fabrication — provides outstanding chemical durability and thermal stability up to 600 °C. Wide wall geometry — ensures stable optical alignment and low background interference. Broad wavelength range — 190 – 2500 nm, suitable for UV/VIS and NIR applications. Typical Applications UV/VIS absorbance measurements with high-concentration or strongly absorbing samples. Protein and nucleic acid quantification at 260/280 nm. Environmental testing and water quality analysis. Industrial QC and analytical research. Short path length applications to reduce signal saturation. Fused Fabrication Notes Fused fabrication provides excellent thermal and chemical resistance. Not suitable for hydrofluoric acid (HF) or strong organic solvents such as toluene and acetone. Powder seams may discolor over time but do not affect optical performance. Typical path length tolerance is ±0.06 – 0.08 mm. Cuvette Specifications Type Absorption Quartz Cuvette Optical Path Length 1.5 mm Article No. VAOF25 Volume 2.5 ml Measuring Method Absorption Cells Clear Walls 50 × 38 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 50 mm Width (Inside) 35 mm Width (Outside) 38 mm Depth (Inside) 1.5 mm Depth (Outside) 4.5 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Fused* Package Cell Only Note: Fused fabrication offers excellent chemical and thermal durability. Avoid use with HF or strong organic solvents. Powder seams may discolor but do not affect measurement accuracy. The short 1.5 mm path length is ideal for high-concentration samples and applications requiring reduced absorbance. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VAOF05) 0.5ml Absorption Cuvette, Fused, Lightpath 3mm, 21.5x10x5 mm, 2 Clear Windows 100 gIn Stock$49.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOFW1) 1ml Absorption Cuvette, Fused, Lightpath 5mm, 20x15x8 mm, 2 Clear Windows 100 gIn Stock$41.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOB8) 8ml Absorption Cuvette, Fused, Lightpath 3mm, 72x42x5 mm, 2 Clear Windows 100 gIn Stock$196.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VCLM15) 1.5/3mm Customized Cuvette, 3 Windows, 2 Ends Open 100 gIn Stock$515.00Add to cart Add to Wishlist Add to Wishlist
