(VAOF190) 19ml Absorption Cuvette, Fused, Lightpath 34mm, 40x38x20 mm, 2 Clear Windows

Description VAOF190 Fused Quartz Long Path Absorption Cuvette is a 2-window quartz cuvette with a 34 mm optical path length and a 19 ml volume. Its long-path design makes it particularly suitable for trace-level absorbance measurements, significantly improving signal sensitivity for low-concentration samples. Why Long Path Length Matters A longer optical path length increases the interaction distance between light and the sample, amplifying weak signals and improving the signal-to-noise ratio. This makes it possible to detect trace analytes with higher accuracy and extend the dynamic measurement range—an essential factor in environmental monitoring, biochemical analysis, and material research. This cuvette is ideal for: Low-concentration or trace-level absorbance analysis Environmental contaminant detection (e.g., nitrates, phosphates, organic pollutants) Biological and chemical assays requiring enhanced sensitivity Research where signal strength and reproducibility are critical Key Features 34 mm optical path — long path length increases absorbance sensitivity. 2-window design — optimized for transmission and absorbance spectroscopy. Fused fabrication — excellent chemical resistance and can be heated up to 600 °C. Wavelength range — 190–2500 nm, suitable for UV/VIS applications. Typical Applications Environmental water analysis (e.g., nitrate, phosphate, heavy metals) Biochemical assays requiring higher detection sensitivity Pharmaceutical and material science research Trace contaminant monitoring and extended signal measurement Fused Fabrication Notes Fused quartz ensures superior clarity, thermal stability, and chemical durability. Not suitable for hydrofluoric acid (HF) or strong organic solvents such as toluene and acetone. Powder seams may discolor over time but do not affect performance. Typical path length tolerance: ±0.06–0.08 mm. Cuvette Specifications Type Absorption Quartz Cuvette Optical Path Length 34 mm Article No. VAOF190 Volume 19 ml Measuring Method Absorption Cells Clear Walls 40 × 20 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 40 mm Width (Inside) 16 mm Width (Outside) 20 mm Depth (Inside) 34 mm Depth (Outside) 38 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Fused* Package Cell Only Note: VAOF190 is a long-path fused quartz cuvette designed to enhance detection sensitivity and precision. It is particularly suited for trace analysis and UV/VIS absorbance measurements. Not recommended for HF or strong organic solvents. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VAOF19) 43mL Large Cuvette, Fused, Lightpath 50mm, 2 Windows, 45x24x54 mm 100 gIn Stock$98.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOF22) 22ml Absorption Cuvette, Fused, Lightpath 50mm, 40x14x52.5 mm, 2 Clear Windows 100 gIn Stock$181.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOF13) 1.3ml Absorption Cuvette, Fused, Lightpath 9mm, 25x8x11 mm, 2 Clear Windows 100 gIn Stock$35.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOF30) 10.5mL Standard Absorption Cuvette with PTFE Lid, Fused, Lightpath 30mm 100 gIn Stock$36.00Add to cart Add to Wishlist Add to Wishlist
