(VAOF10) 10ml Absorption Cuvette, Fused, Lightpath 10mm, 102x14x14 mm, 2 Clear Windows

Description VAOF10 Fused Quartz Absorption Cuvette is a 2-window cuvette with a 10 mm optical path length and a 10 ml volume. This model is a typical long-path cuvette, designed to enhance detection sensitivity and enable accurate measurement of low-concentration samples in UV/VIS spectroscopy. The extended optical path increases the interaction between the light beam and the sample, amplifying weak absorbance signals. This makes VAOF10 particularly valuable in trace analysis, environmental testing, and advanced R&D applications where high sensitivity is required. Key Features 10 mm optical path — standard long-path design for improved detection of low-concentration samples. 10 ml capacity — provides sufficient volume for routine and research-grade assays. Fused quartz construction — delivers excellent UV transparency, chemical resistance, and thermal stability. Broad wavelength range — 190–2500 nm, suitable for UV, visible, and NIR spectroscopic measurements. 2-window configuration — ideal for standard absorbance and transmission applications. Typical Applications Trace detection of chemical and biological analytes Environmental monitoring and water quality testing Pharmaceutical and biochemical research UV/VIS spectroscopy for low-concentration measurements General laboratory and R&D use Fused Fabrication Notes Fused quartz provides outstanding optical clarity, high temperature resistance, and solvent compatibility. Not suitable for hydrofluoric acid (HF) or aggressive organic solvents like toluene and acetone. Powder seams may discolor over time but do not affect optical performance. Typical path length tolerance: ±0.06–0.08 mm. Cuvette Specifications Type Absorption Quartz Cuvette Optical Path Length 10 mm Article No. VAOF10 Volume 10 ml Measuring Method Absorption Cells Clear Walls 102 × 14 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 102 mm Width (Inside) 10 mm Width (Outside) 14 mm Depth (Inside) 10 mm Depth (Outside) 14 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Fused* Package Cell Only Note: VAOF10 is a long-path fused quartz cuvette that provides enhanced sensitivity for low-concentration measurements. It is ideal for trace analysis, environmental testing, and research applications that require precise absorbance detection. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VAOF17) 17ml Absorption Cuvette, Fused, Lightpath 10mm, 63x32x14 mm, 2 Clear Windows 100 gIn Stock$217.00Add to cart Add to Wishlist Add to Wishlist 13% Add to Wishlist Add to Wishlist (VAOFW5) 3.5mL Absorption Cuvette with PTFE Lid, Fused, Flat Base, Lightpath 10mm 100 gIn Stock$33.00 Original price was: $33.00.$29.00Current price is: $29.00.Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOF16) 16mL Colorimeter Cuvette, Fused, Lightpath 10mm, 62.5 x 32 x 14 mm 100 gIn Stock$219.00Add to cart Add to Wishlist Add to Wishlist 6% Add to Wishlist Add to Wishlist (VFOB20) 1.9mL Custom Cuvette, 20x12x12 mm, 4 Windows, Bonded, Lightpath 10 mm 100 gIn Stock$52.00 Original price was: $52.00.$49.00Current price is: $49.00.Add to cart Add to Wishlist Add to Wishlist
