(VAOF05) 0.5ml Absorption Cuvette, Fused, Lightpath 3mm, 21.5x10x5 mm, 2 Clear Windows

Description VAOF05 Fused Quartz Microvolume Cuvette is a 0.5 ml capacity custom cuvette designed for high-precision absorption spectroscopy with a 3 mm optical path length. Its compact structure (21.5 × 10 mm) and low internal volume make it ideal for micro-volume analysis, OEM instruments, and specialized analytical applications. This model showcases our custom fabrication capabilities, offering exceptional clarity and dimensional precision for laboratories working with small or precious sample volumes. Key Features 3 mm optical path — optimized for short-path absorbance measurements with low sample volumes. 0.5 ml capacity — ideal for micro-volume and high-value sample testing. Custom dimensions — fits specialized and OEM instrument designs. Fused quartz material — excellent UV transparency, thermal stability, and resistance to most chemicals. Broad wavelength range: 190–2500 nm — compatible with UV/VIS/NIR spectroscopic applications. Typical Applications Micro-volume absorption spectroscopy Biochemical and clinical diagnostics High-value or precious sample testing OEM and custom analytical systems Environmental and trace detection Fused Fabrication Notes Fused quartz provides superior optical transmission and thermal stability up to 600 °C. Not suitable for hydrofluoric acid (HF) or aggressive organic solvents such as toluene or acetone. Powder seams may discolor over time but do not impact optical accuracy. Typical dimensional tolerance: ±0.06–0.08 mm. Cuvette Specifications Type Microvolume Quartz Cuvette Optical Path Length 3 mm Article No. VAOF05 Volume 0.5 ml Measuring Method Absorption Cells Clear Walls 21.5 × 10 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 21.5 mm Width (Inside) 8 mm Width (Outside) 10 mm Depth (Inside) 3 mm Depth (Outside) 5 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Fused* Package Cell Only Note: VAOF05 is a fused quartz micro cuvette designed for low-volume absorption measurements. Its small path length and precise custom dimensions make it an excellent choice for advanced laboratory and OEM instrument applications. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VFOF03) 2.1 mL Dual Pathlength Cuvette, Fused, Lightpath 3mm or 20mm, 45×22.5×5.5 mm 100 gIn Stock$257.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOB8) 8ml Absorption Cuvette, Fused, Lightpath 3mm, 72x42x5 mm, 2 Clear Windows 100 gIn Stock$196.00Add to cart Add to Wishlist Add to Wishlist 24%Hot Add to Wishlist Add to Wishlist (VAOF3) 1.05mL Absorption Cuvette with PTFE Lid, Fused, Round Base, Lightpath path 3mm 100 gIn Stock$38.00 Original price was: $38.00.$29.00Current price is: $29.00.Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VCLB03) 3.5mL Flow Cuvette with 2 Ends Open, Lightpath 3mm, 2 Windows, Bonded 100 gIn Stock$123.00Add to cart Add to Wishlist Add to Wishlist
