(VAOB85) 8.5ml Fluorescence Cuvette, Bonded, Lightpath 28mm, 12x30x30 mm, 4 Clear Windows

Description VAOB85 Bonded Quartz Fluorescence Cuvette is a 4-window cuvette with a 28 mm optical path length and an 8.5 ml volume. It features a wide clear wall design, ideal for fluorescence measurements that require side detection and enhanced optical clarity. Bonded fabrication ensures cost-effective construction and good chemical resistance under typical laboratory conditions. Key Features 28 mm optical path length — suitable for high-sensitivity fluorescence and absorbance measurements. 4-window design — allows side detection, enabling fluorescence excitation and emission experiments. Bonded fabrication — provides stable performance for most general laboratory applications. Wide wall geometry — optimized for fluorescence setups with precise optical alignment. Broad wavelength range — 190 – 2500 nm, suitable for UV/VIS and NIR applications. Typical Applications Fluorescence spectroscopy (side detection and excitation). UV/VIS absorbance and transmission studies. Routine lab assays and standard optical experiments. Educational and R&D environments where cost-effective bonded construction is preferred. Bonded Fabrication Notes Bonded fabrication offers cost-effective performance for routine measurements. Not recommended for high-temperature applications or long-term solvent exposure. Bonded seams are more sensitive to aggressive organic solvents compared to fused fabrication. Suitable for aqueous and mild solvent environments. Cuvette Specifications Type Fluorescence Quartz Cuvette Optical Path Length 28 mm Article No. VAOB85 Volume 8.5 ml Measuring Method Fluorescence Cells Clear Walls 12 × 30 mm Number of Windows 4 Wavelength Range UV/VIS (190 – 2500 nm) Height 12 mm Width (Inside) 28 mm Width (Outside) 30 mm Depth (Inside) 28 mm Depth (Outside) 30 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Bonded* Package Cell Only Note: Bonded fabrication is ideal for standard fluorescence and absorbance work but is less durable than fused quartz for extreme conditions. The 4-window design supports precise fluorescence measurement with good optical clarity and light transmission. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VFML50N) 125 mL Large Cuvette, 4 Windows, No Cover, Molded, Lightpath 50mm, 52x54x54 mm 500 gIn Stock$351.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VFFL30N) 27 mL Large Cuvette, 4 Windows, No Cover, Fused, Lightpath 30mm, 32x34x34 mm 200 gIn Stock$196.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VFFL20N) 8 mL Large Cuvette, 4 Windows, No Cover, Fused, Lightpath 20mm, 22x24x24 mm 100 gIn Stock$154.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VCOF20-N) 3mL Custom Cuvette, 5 Windows, no cover, Fused, Lightpath 20mm, 8.5x21x21 mm 100 gIn Stock$293.00Add to cart Add to Wishlist Add to Wishlist
