(VAOB20) 2ml Cuvette, Bonded, Lightpath 8.5mm, Large Opening, 8x45x12.5 mm, 2 Windows

Description VAOB20 Bonded Quartz Absorption Cuvette is a 2-window cuvette with an 8.5 mm optical path length and a 2 ml volume. It features a large opening and wide clear wall design, making it easy to load and clean, while maintaining stable optical transmission for UV/VIS measurements. Bonded fabrication provides a cost-effective solution for routine laboratory applications. Key Features 8.5 mm optical path length — ideal for standard UV/VIS absorbance measurements and medium concentration samples. 2-window design — optimized for straight-beam spectroscopy. Bonded fabrication — cost-effective with good chemical resistance under typical laboratory conditions. Large opening design — easy to fill, clean, and handle samples. Broad wavelength range — 190 – 2500 nm, suitable for UV/VIS and NIR applications. Typical Applications UV/VIS absorbance and transmission studies. Routine lab assays and standard optical experiments. Protein and nucleic acid quantification at 260/280 nm. Environmental and chemical analysis. General research and educational laboratory use. Bonded Fabrication Notes Bonded fabrication offers cost-effective performance for standard applications. Not recommended for high-temperature use or aggressive organic solvents. Best suited for aqueous and mild solvent environments. Typical path length tolerance is ±0.06 – 0.08 mm. Cuvette Specifications Type Absorption Quartz Cuvette Optical Path Length 8.5 mm Article No. VAOB20 Volume 2 ml Measuring Method Absorption Cells Clear Walls 8 × 45 mm Number of Windows 2 Wavelength Range UV/VIS (190 – 2500 nm) Height 8 mm Width (Inside) 41 mm Width (Outside) 45 mm Depth (Inside) 8.5 mm Depth (Outside) 12.5 mm Center Height (Z) 8.5 – 20 mm Fabrication Method Bonded* Package Cell Only Note: Bonded fabrication is economical and suitable for most standard absorbance applications. Not recommended for use with strong solvents or at high temperatures. The large opening design provides easy handling and cleaning, ideal for routine lab use. Comparison of Fabrication Types 1234 *Molded*Fused*Bonded / Glued UV vis ( 190- 2500 nm)YesYesYes Transmission Matched On RequestNoNo Transmission > 80%YesYesYes Resistant to Acids and Bases (except hydrofluoric acid)YesYesNo Resistant to Organic SolventsYesYesNo Usable upto 600°C (1112°F)YesYesYes Usable upto 1200°C (2192°F)YesNoNo 0 Variations ReadingOn RequestNoNo FabricationMoldedAssembled with Quartz PowderAssembled with Glue AdhesivesNoNoYes StorageShort Term StorageClean After UseClean After Use Available MaterialFused Quartz Material NoteMolded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm.   1 QVARZ Cuvettes Transmission Characteristics The following table is our cuvettes and cells made of quartz material suitable for wavelength from 190nm to 2500nm and depicts the percentage transmission for the material. IR or Glass material is not included. Why QVARZ Cuvettes and Cells?QVARZ is world-renowned as the producer of premium quartz cuvettes. Over fifteen years of experience manufacturing quartz cuvettes ensures that every QVARZ cuvettes are manufactured to the most exacting standards for reproducible results. Spectrophotometry cuvettes - Most spectrophotometry applications in the visible and UV ranges benefit from QVARZ spectrophotometry cuvettes. Our cuvettes made of fused quartz material deliver precise and reliable readings even at wavelengths as low as 190 nm. QVARZ cuvettes are compatible with most spectrophotometers and photometers with standard 0.2 - 100 mm path lengths. Fluorometry cuvettes - QVARZ brings two decades of experience molding high-quality spectrophotometry cuvettes to new four-sided clear cuvettes for fluorometry. Available in standard quartz material with ultra-low auto-fluorescence for the highest precision measurements. Protective packaging - QVARZ cuvettes are encased in dust-free, low scratching expanded polystyrene packaging. This ensures that premium cuvettes arrive in the laboratory ina the same pristine condition they were in at the factory, with optical quality windows and free of contaminants.  Volumes for most purposes - Our cuvettes are available in a variety of ranges from macro to macro semi-micro sizes to respond to the needs of most scientific applications. We are also able to customize sample volume to deliver consistent, accurate findings. Perform consistently - QVARZ Cuvettes are constructed from high-quality fused quartz materials and are grouped by manufacturing mold cavities to ensure the lowest fluctuation in extinction coefficient. Customization - Custom cuvettes and cells are encouraged and available upon request; mechanical drawings with specifications and tolerances are prerequisites. Awesome pricing and flexibility on small quantities.  To the best of our knowledge, the technical information provided here is accurate. However, Qvarz.com assumes no liability for the accuracy of this information. The values provided here are typical at the time of manufacture and may vary over time and from batch to batch. Related products Add to Wishlist Add to Wishlist (VCOF20-N) 3mL Custom Cuvette, 5 Windows, no cover, Fused, Lightpath 20mm, 8.5x21x21 mm 100 gIn Stock$293.00Add to cart Add to Wishlist Add to Wishlist Add to Wishlist Add to Wishlist (VAOF06) 0.6ml Cuvette, Fused, Lightpath 10mm, Large Opening, 5x24x14 mm, 2 Clear Windows 100 gIn Stock$41.00Add to cart Add to Wishlist Add to Wishlist 15% Add to Wishlist Add to Wishlist (VFOB08) 3mL Custom Cuvette, 33x8x23 mm, 5 Windows, Bonded, Lightpath 20/30 mm 120 gIn Stock$103.00 Original price was: $103.00.$88.00Current price is: $88.00.Add to cart Add to Wishlist Add to Wishlist
